Direct Mount

Part Number	Size (inches)	Pressure Rating @ 170°F.	End Connection	A	B	C	ISO-5211	STP File
384305TEF4	1/2	1,000 PSI	Clamp	3.50	2.78	.354 (9mm)	F04 F05
384307TEF4	3/4	1,000 PSI	Clamp	3.98	2.91	.354 (9mm)	F04 F05	STP
384310TEF4	1	1,000 PSI	Clamp	4.49	3.36	.433 (11mm)	F04 F05	STP
384315TEF4	1-1/2	1,000 PSI	Clamp	5.51	3.92	.551 (14mm)	F05 F07	STP
384320TEF4	2	1,000 PSI	Clamp	6.14	4.24	.551 (14mm)	F05 F07	STP
384325TEF4	2-1/2	800 PSI	Clamp	7.76	5.74	.669 (17mm)	F07 F10	STP
384330TEF4	3	800 PSI	Clamp	9.02	6.09	.669 (17mm)	F07 F10	STP
384340TEF4	4	800 PSI	Clamp	9.48	7.40	.866 (22mm)	F10	STP
384360TEF4	6	250 PSI	Clamp	N/A	N/A	N/A	N/A
